Compact Night Vision XQ23V Thermal Scope, thermal monocular scope, hunter night vision

FOB Reference Price:Get Latest Price
$1,800.00 - $2,500.00 / Unit | 1 Unit/Units Night Vision Goggles (Min. Order)
Support Sea freight
Report Suspicious Activity
Quick Details
Place of Origin:
Russian Federation
Brand Name:
Model Number:
200x86x59 mm
350 g
Night vision thermal scopes, thermal scope
Effective Visual Distance:
Operating Voltage:
4 / 6
Product name:
Pulsar Quantum Lite XQ23V Thermal Scope SKU 77337
Objective Lens:
Digital zoom:
2x / 4x
Diopter adjustment, dptr:
+/- 5
Range of dectection:
Microbolometer resolution:
384 x 288 pix
Display resolution:
640 x 480 pix
Display type:
Field of view:
16.5° x 12.4°
Supply Ability
Supply Ability:
10000 Unit/Units per Month Night Vision Goggles
Packaging & Delivery
Packaging Details
Compact Night Vision XQ23V Thermal Scope, thermal monocular scope, hunter night vision
What's in the box
Thermal Imaging Scope Quantum Lite XQ30V | Carrying case | User manual | Video cable | Hand strap | Spare battery container | Cleaning cloth | Warranty card
Guang Zhou
Lead Time :
Within 15 days after payment

Compact Night Vision XQ23V Thermal Scope, thermal monocular scope, hunter night vision


Product Description




Electronic components                                               Optical characteristics

Frame Rate, Hz:     50                                          Close-up distance, m: 3

Microbolometer resolution, pixels:  384x288

Pixel Pitch, µm:     17                                          Range of Detection, m

Display type:         AMOLED                                 Range of detection, m

Display Resolution, pix.:       640x480                   (object high*width = 1,7*0,5m): 800


Optical characteristics                                                  Power Supply

Magnification, x:     1.8 ... 7.2                                           Power Supply, V: 4/ 6

Digital zoom, x:    2x; 4x                                      Battery type: 4xAA

Objective Lens:     F22.5/1.4                                 Battery Life, hour: 5.5 ... 6.5 (video out off)

Field of View,°, horizontal * vertical:  16.5x12.4      External Power Supply: DC 8.4 ÷ 15

Horizontal Field of view, m @100m:   29

Exit pupil, mm:           8                                       Physical & operational characteristics

Eye Relief, mm: 20                                               Start-up time, seconds: 5

Diopter adjustment, dptr.: ± 5                               Remote control: wireless.

                                                                          Operating Temperature,°C: - 25 … +50

                                                                           Level of Protection (acc. to IEC 60529): IPX4

                                                                           Dimensions, mm: 200x86x59


                                                                                              Weight (without batteries), kg: 0.35

Product Details


Company Information


Established in 2009, MARCOOL Optical Instrument CO., LTD specializes in managing the “MARCOOL ” brand and has been engaged in the design, manufacture and sale of most of the optical instruments, including rifle scope, binocular, monocular ,spotting scope, night vision, laser sight, red dot etc.

Relying on the major developing and manufacture technology,during the past 20 years, we have focused on the riflescope and other hunting optics at the wholesale and retail domestic and abroad. Our marketing networks now are widely distributed in Europe, North America, South Africa, Asia and so on.


Our Service


Service:                                                                                     Payment:

* OEM & ODM are availible;                                                                            * T/T

* Customized logo service;                                                                              * WesternUnion

* Inquiry & consulting support;                                                                          * MoneyGram

* Small trial order / Sample testing support;                                                   * Escrow

* View our office & factory;                                                                               * AliPay

* Fast & Cheap delivery;                                                                                   * PayPal

* 24 months warranty.                                                                                       (PayPal only available for Marcool brand products)


We claim

• Delivery in 7 days after deposit in stock
• All Marcool scopes have 48 months warranty
• Packages tracking and Products’ arrival reminding .
• OEM & ODM are Available,and out package could also be customized
• The corresponding compensation can be provided for products’quality problems.
• Help you on products recommendations and market positioning for your reference
• Any one will be kindly treated as our friend no matter you are a small or a new customer.
• Commited to your 100% satisfication through both products' quality and considerable service,all the time




Packing & Shipping



With very strict packing, Use K=K Top Quality Carton Box and Well Packed with Stryrofoam Peanuts. We ensure products can avoid any damage during transportation.



We can search and recommend the right Delivery Channel for you. Includes Air Freight Transport, Door to Door Express Shipping such as DHL, UPS, Fedex,EMS,etc. With 10 years experience on international trading, We are confident to help you transport your order security and efficiently.



We guarantee that the items will be shipped out within 7 days in stock.
Please make sure the address is cor rect.
Delivery time depends on the destin ation and other factors.
